Casio CDP-120 Service Manual

CDP-120
– 13 –
A-10. Undo two screws on the RIGHT-SIDE-INNER-CASE and then remove the right panel unit.
RIGHT-SIDE-INNER-CASE
Right panel unit
A-11. Undo two screws on the LEFT-SIDE-INNER-CASE and then remove the left panel unit.
LEFT-SIDE-INNER-CASE
Left panel unit

Casio CDP-120 Specifications

General

Sound effects	Reverberation
Number of speakers	2
Chorus effects quantity	5
Maximum polyphony (notes)	48
Reverberation effects quantity	10
USB version	2.0
USB connector type	USB Type-B
Keys quantity	88 keys
Product color	Black

Weight and Dimensions

Depth	286 mm
Width	1322 mm
Height	129 mm
Weight	11400 g
