Casio CDP-120 Service Manual

CDP-120
– 31 –
1: CDP-120_BLACK_DI
2: CDP-120_BLACK_EU
3: CDP-120_BLACK_UK
4: CDP-120_BLACK_US
1234
MAIN PCB
N 1 10399371 PCB UNIT/MAIN TK-RJM511112*001 1111 AMDA1
CN19 10236624 CONNECTOR/USB UBR24-4K5G00 1111 C
D6,D7 10009218 DIODE 1SS400TE61 2222 X
IC5 10211950 IC NJM2068M-D(TE1) 1111 X
IC11 10137770 IC TC7S08FU(TE85L.F) 1111 X
N IC6 10398240 IC XC6402FV36PR-G 1111 X
N IC2 10396325 LSI/MEMORY MX29LV640EBTI-70G 1111 C
L11 10193074 COIL DLW21HN181SQ2L 1111 X
Q7,Q8 69300298 TRANSISTOR 2SC4081T106R 2222 X
X1 10375016 RESONATOR 7V48080006 1111 X
POWER AMP PCB
N 2 10399370 PCB UNIT/PSA1 TK-RJM511113*001 1111 BPSA1
N D1,D2 10260786 DIODE 1N5822-C144 2222 X
IC3 10375029 IC LA5756-MDB-E 1111 X
IC2 10306512 IC TDA7297 1111 X
J5 10206815 JACK/PEDAL JY-6314*01-030 1111 B
J2 10305218 JACK/PHONE JY-6316B*01-070 1111 B
J3 10334294 JACK/DC KM02022ABMP 1111 A
L2 10231919 COIL RB53-856396NP 1111 X
L3,L4,L6 10231920 COIL RB53-856397NP 3333 X
L5 10232457 COIL RII7-860400NP 1111 X
N VR1 10407265 VARIABLE RESISTOR F164KPD-1N-CASIO-4 1111 BMain volume
D3,D4 23901820 DIODE 1SS355TE-17 2222 X
IC1 10306415 IC BH3547F-E2 1111 X
Q4 69409403 TRANSISTOR 2SA1576AT106R 1111 X
Q1-Q3 69300298 TRANSISTOR 2SC4081T106R 3333 X
KEYBOARD PCB
3 10399792 PCB UNIT/KY and RUBBER CONTACT TK-RJM511215*001 1111 CKYA1/KYB1/KYC1
N D801-D827 10398230 DIODE DAN202UMTL 27 27 27 27 X
N D828-D861 10398230 DIODE DAN202UMTL 34 34 34 34 X
N D862-D888 10398230 DIODE DAN202UMTL 27 27 27 27 X
4 10195879 RUBBER CONTACT/AG RJM502920-001V02 7777 A
5 10195880 RUBBER CONTACT/GC RJM502921-001V02 1111 B
KEYBOARD UNIT
6 10399791 KEYBOARD UNIT TK-RJM511279*001 1111 C
N 7 10363265 WHITE KEY/SA RJM502795-003V05 1111 X
N 8 10398222 WHITE KEY/B RJM502794-001V04 1111 A
N 9 10398223 WHITE KEY/CEGB RJM502862-001V04 7777 A
N 10 10398225 WHITE KEY/DFA RJM502863-001V04 7777 A
N 11 10363266 WHITE KEY/SC RJM502796-003V05 1111 X
N 12 10398220 BLACK KEY RJM502797-001V03 36 36 36 36 A
13 10341062 HAMMER UNIT/W1 TK-RJM509600*001 13 13 13 13 C
14 10341063 HAMMER UNIT/W2 TK-RJM509601*001 13 13 13 13 C
15 10341064 HAMMER UNIT/W3 TK-RJM509602*001 13 13 13 13 C
16 10341065 HAMMER UNIT/W4 TK-RJM509603*001 13 13 13 13 C
17 10341066 HAMMER UNIT/B1 TK-RJM509604*001 9999 C
18 10341067 HAMMER UNIT/B2 TK-RJM509605*001 9999 C
19 10341068 HAMMER UNIT/B3 TK-RJM509606*001 9999 C
20 10341069 HAMMER UNIT/B4 TK-RJM509607*001 9999 C
Specification R RemarksN Item Code No. Parts Name
Price
Code
Q'ty

Casio CDP-120 Specifications

General

Sound effects	Reverberation
Number of speakers	2
Chorus effects quantity	5
Maximum polyphony (notes)	48
Reverberation effects quantity	10
USB version	2.0
USB connector type	USB Type-B
Keys quantity	88 keys
Product color	Black

Weight and Dimensions

Depth	286 mm
Width	1322 mm
Height	129 mm
Weight	11400 g
