Casio CDP-120 Service Manual

CDP-120
– 32 –
1: CDP-120_BLACK_DI
2: CDP-120_BLACK_EU
3: CDP-120_BLACK_UK
4: CDP-120_BLACK_US
1234
Specification R RemarksN Item Code No. Parts Name
Price
Code
Q'ty
21 10336108 CABLE UL2896-30-265-MACP 1111 X
N 22 10398226 FELT/LOWER LIMIT/BLACK KEY RJM510067-002V02 1111 X
N 23 10398227 FELT/LOWER LIMIT/WHITE KEY RJM503562-002V02 1111 X
N 24 10398219 FELT/UPPER LIMIT/HAMMER RJM511203-001V01 1111 X
25 10399793 FELT/LOWER LIMIT/HAMMER TK-RJM507910*001 1111 X
26 10388000 PLATE RJM510952-001V01 1111 X
27 10343387 FABRIC TAPE/ACP RJM510100-001V01 1111 X
28 10175757 PACKING/10X386 RJM504743-001V01 2222 X
29 10128574 PACKING RJM503241-001V01 1111 X
N 30 69307137 PACKING M440857-1 4444 X
N 31 10397766 KEYBOARD SEALING RJM511107-001V01 2222 X
32 10175758 PACKING/10X100 RJM504744-001V01 2222 X
33 69287160 SPONGE/50X180 M440961-1 1111 X
PANEL UNIT
N 34 10398589 CASE/PANEL RJM511090-001V01 1111 X
35 10269765 KNOB/ROTARY M341109-008V01 1111 C
N 36 10398202 BRACKET RJM511073-001V01 2222 X
N 37 10398204 RUBBER BUTTON/A RJM511075-001V01 1111 X
SIDE PANEL UNIT
N 38 10398236 CASE SUB UNIT/PANEL/LEFT RJM511005*001V01 1111 X
N 39 10398237 CASE SUB UNIT/PANEL/RIGHT RJM511006*001V01 1111 X
40 10130104 FABRIC TAPE/10X180 M440259-002V01 2222 X
41 10284878 SPEAKER C0612J01 2222 X
N 42 10164046 HARNESS EH-2P-43-M420 1111 X
43 10308814 HARNESS EH-2P-85-M810 1111 X
44 69320969 SPONGE/50X285 M441325-1 2222 X
N 45 10312787 SPONGE/50X115 RJM506431-002V01 2222 X
MAIN CASE UNIT
46 10399794 CASE UNIT/LOWER TK-RJM510997*001 1111 X
47
10201510 BRACKET RJM505933-001V01 4 4 4 4 X
N 48 10359076 BRACKET RJM505932-001V02 2222 X
49 10133655 RUBBER FOOT RJM503180-001V01 5555 X
N 50 10398588 CASE/SIDE/LEFT RJM510999-002V01 1111 X
N 51 10398197 CASE/SIDE/RIGHT RJM511000-001V01 1111 X
N 52 10398216 CASE/SIDE/INNER/LEFT RJM511001-001V01 1111 X
N 53 10398217 CASE/SIDE/INNER/RIGHT RJM511002-001V01 1111 X
54 10179177 FABRIC TAPE/6X310 RJM505229-001V01 2222 X
55 69307162 PACKING M440967-1 2222 X
56 10337052 LOWER COVER RJM509409-001V01 8888 X
ACCESSORIES
- 10342718 MUSIC STAND RJM508666-001V04 1111 C
- 10133504 FOOT PEDAL/SP3 TK-RJM503195*001 1111 X
- 10392266 AC ADAPTOR AD-A12150LW-F3 1111 Bwithout AC CORD
- 10361066 AC CORD UC2LT-M006A 1 1 X for US
- 10361067 AC CORD EC2LT-M002A 1 1 X for EU
- 10361068 AC CORD KC2LT-M002A 1 X for Korea
- 10361069 AC CORD AUC2LT-M002A 1 X for Australia
- 10361070 AC CORD BC2LT-M002A 1 X for UK

Casio CDP-120 Specifications

General

Sound effects	Reverberation
Number of speakers	2
Chorus effects quantity	5
Maximum polyphony (notes)	48
Reverberation effects quantity	10
USB version	2.0
USB connector type	USB Type-B
Keys quantity	88 keys
Product color	Black

Weight and Dimensions

Depth	286 mm
Width	1322 mm
Height	129 mm
Weight	11400 g
