Casio CTK-6200 User Manual

E-32
Applying Effects to a Sound
You can apply a variety of different acoustic effects to the sounds produced by the Digital Keyboard. The built-in effects include a
wide variety of variations that give you access to a selection of general digital effects.
• The WK-6600 also lets you apply effects to input from the T-5 (MIC IN) jack.
The following shows how Digital Keyboard effects are configured.
• Items such as “Reverb Send” that are indicated by the symbol are all mixer settings. For details, see “Using the Mixer”
(page E-38).
• Chorus and DSP cannot be used at the same time.
■ Chorus Effect Mode Configuration
The chorus effect mode is enabled while “Chorus” is selected for the “Chorus/DSP” effect parameter. Chorus and reverb can be
used in the chorus effect mode.
• For information about “Chorus/DSP”, see “Selecting an Effect” (page E-34).
Configuration of Effects
Part Volume/Pan
Reverb Send
Reverb
Chorus
Master
Volume/Pan
Chorus Send
Part Volume/Pan
Mic In
Reverb Send
Chorus Send
Tone
Generator
Part A01-A16, B01-B16
External Input
Output
Mono
Stereo
(Area within the broken line is for WK-6600 only.)

Casio CTK-6200 Specifications

General

Sound effects	Chorus, Equalization, Reverberation
Tones quantity	700
Tweeter diameter	30 mm
Metronome tempo range	30 - 255 bpm
Chorus effects quantity	5
Compatible memory cards	SD, SDHC
Metronome beats per bar	0, 2, 3, 4, 5, 6
Maximum memory card size	32 GB
Maximum polyphony (notes)	48
Mid-range driver diameter	120 mm
Reverberation effects quantity	10
USB connector type	USB Type-B
Keys quantity	61 keys
Product color	Black

Weight and Dimensions

Depth	384 mm
Width	948 mm
Height	122 mm
Weight	5700 g
