Casio CTK-6200 User Manual

Using the Tone Editor
E-48
DSP On Off
(DSP On/Off)
Specifies whether DSP should be applied (on) or not applied (oFF) to notes.
The following four settings become enabled when “on” is selected for this
setting.
oFF
*
, on
DSP Specifies the DSP to be applied to tones using DSP numbers (001 to 100:
Preset DSPs; 101 to 200: User DSPs). Selecting “ton” applies the initial preset
DSP of each tone.
ton
*
, 001 - 200
DSP Type
(DSP Type)
Shows the DSP type number corresponding to the above DSP value that is set
automatically as the initial default setting.
*1
You can modify the initial default
setting and select a different DSP type.
01 - 46
*1
DSP Parameters 1
through 8
Shows up to eight parameters for “DSP Type”.
*2 *2
DSP RevSend
(DSP Reverb Send)
Adjusts how much reverb is applied to the post-DSP note. 0 - 40
*
- 127
*1 See “Preset DSP List” (page E-119) for information about the DSP types of each preset DSP.
*2 The number of DSP parameters, their content, and their setting ranges depend on the DSP type. For details, see “DSP Type
List” (page E-120) and “DSP Parameter List” (page E-121).
Parameter Name Description Setting Range

Casio CTK-6200 Specifications

General

Sound effects	Chorus, Equalization, Reverberation
Tones quantity	700
Tweeter diameter	30 mm
Metronome tempo range	30 - 255 bpm
Chorus effects quantity	5
Compatible memory cards	SD, SDHC
Metronome beats per bar	0, 2, 3, 4, 5, 6
Maximum memory card size	32 GB
Maximum polyphony (notes)	48
Mid-range driver diameter	120 mm
Reverberation effects quantity	10
USB connector type	USB Type-B
Keys quantity	61 keys
Product color	Black

Weight and Dimensions

Depth	384 mm
Width	948 mm
Height	122 mm
Weight	5700 g
