Using the Song Sequencer
E-92
1.
Perform steps 1 through 5 under “To adjust the
velocity value of a note event” on page E-91. In
step 4, select “GatetimeMod.” instead of
“VelocityMod.”.
2.
Press the R-16 (ENTER) button.
• This will display the setting screen like the one shown
below.
• The following explains the meanings and setting ranges
of the on-screen items. The settings marked with an
asterisk (*) in the “Setting Range” column are initial
defaults.
3.
To change the setting to the desired value,
press the R-16 (ENTER) button.
4.
In response to the “Sure?” message that
appears, press the R-14 (YES) button to execute
the adjustment or the R-14 (NO) button to
cancel.
1.
Perform the procedure under “To start an event
editor operation” on page E-80 to display the
event editor menu.
2.
Use the R-17 (y) button to move the 0 to
“Beat” and then press the R-16 (ENTER) button.
• This displays the “Beat” screen.
3.
Use the R-17 (t, y) buttons to move the
cursor to the beat event you want to delete.
4.
Press the C-8 (DELETE) button.
• The event at the current cursor position will be deleted
as soon as you press the C-8 (DELETE) button.
To adjust the gate time value of a note event
Item name Description Setting Range
Fix
(Fixed value)
Specifies a fixed value as
the time gate value. 99:95
stands for quarter note 99
beats, 95 ticks.
Select “oFF” for this setting
to adjust based on the
current gate time value of
each note event.
oFF
*
,
00:00 to 99:95
Rate
(Gate Time Rate)
These settings are enabled
only when the “oFF” is
selected for the “Fix”
setting. They change the
gate time value of each
note event according to the
mathematical expression
(decimal parts cut off)
shown below. 00:00 is used
when the value produced
by the expression is less
than 00:00, and 99:95 is
used when it is greater than
99:95.
(Current gate time) X (Rate
setting) + (Offset setting)
000% to 100%
*
to
200%
Offset
(Gate Time Offset)
–9:95 to 0:00
*
to
+9:95
To delete a beat event
To Next Page
