E-43
Connecting the USB Cradle Power Supply
Use the optional AC adaptor (AD-S15050B) for the power supply of the USB Cradle.
Always make sure to connect the AC adaptor to the USB Cradle before performing
communication with the Handheld Terminal. Power to the Handheld Terminal is
supplied from the USB Cradle.
1. Plug the AC adaptor into the AC adaptor jack on the back of the USB Cradle.
2. After connecting the power cable to the AC adaptor, plug the other end of it into an
electrical outlet.
3. Connect the USB cable (DT-380USB-A) to the USB client port on the back of the
USB Cradle, and then connect it to the PC.
PC
To Next Page
