Casio Exilim EX-FC100 User Manual

106
Viewing Snapshots and Movies
1. Use the AV cable that comes with the camera to connect it to the TV.
• Make sure that you insert the cable connector into the USB/AV port until you
feel it click securely into place. Failure to insert the connector fully can result in
poor communication or malfunction.
• Note that even while the connector is fully inserted, you
still will be able to see the metal part of the connector as
shown in the illustration.
• Make sure that the camera is turned off before plugging
in or unplugging the cable. Check the user
documentation that comes with the TV for information
about requirements before plugging into or unplugging from the TV.
2. Turn on the TV and select its video input mode.
If the TV has more than one video input, select the one where the camera is
connected.
Viewing Snapshots and Movies on a TV Screen
Yellow
AV cable (bundled)
USB/AV port
White
Making sure that the 6 mark on the
camera is aligned with the 4 mark of the
AV cable connector, connect the cable to
the camera.
AudioVideo
VIDEO IN jack (yellow)
AUDIO IN jack (white)
TV

Casio Exilim EX-FC100 Specifications

General

Megapixel	10.29 MP
Camera type	Compact camera
Sensor type	CMOS
Image sensor size	1/2.3 \
Digital zoom	4 x
Optical zoom	3 x
Combined zoom	12 x
Interface	USB/AV
Digital SLR	No
Built-in flash	Yes
Camera shutter speed	1 - 1/1000 s
Effective sensor resolution	9100000 pixels
Auto focusing (AF) modes	Spot Auto Focus
Closest focusing distance	0.3 m
ISO sensitivity	100
Motion JPEG frame rate	30 fps
Video formats supported	AVI
Maximum video resolution	1280 x 720 pixels
Display diagonal	2.7 \
Display resolution (numeric)	230400 pixels
USB version	2.0
Product color	Black
Battery type	NP40
Flash modes	auto, Flash off, Red-eye reduction
Compatible memory cards	sd
White balance	auto, daylight, manual, Shade, Tungsten

Weight and Dimensions

Depth	22.6 mm
Width	99.8 mm
Height	58.5 mm
Weight	146 g
