Casio Privia PX-S1000 User Manual

EN-41
Reference
• Specifications and designs are subject to change without notice.
Inputs/Outputs
PHONES jacks Stereo mini jacks (3.5mm) × 2
Power 12V DC
AUDIO IN jack Stereo mini jack (3.5mm)
Input impedance: 10kΩ
Input voltage: 200mV
LINE OUT R, L/MONO jacks Standard jacks (6.3mm) × 2
Output impedance: 2.3kΩ
Output voltage: 1.3V (RMS) MAX
USB port Type B
DAMPER PEDAL jack Standard jack (6.3mm)
PEDAL UNIT jack Proprietary jack
Acoustics
Amp output 8W + 8W
Speakers 16cm × 8cm (oval) × 2
Power Supply 2-way
Batteries 6 AA-size alkaline batteries
Continuous Operation Playback of built-in demo songs for approximately 4 hours* on alkaline batteries
* Volume set at 50%. At maximum volume, low battery will be indicated (all touch
buttons, except for 3 FUNCTION flashing) after about two hours.
AC Adaptor AD-A12150LW
Auto Power Off Approximately four hours (under AC adaptor power) or six minutes (under battery
power) after last operation; Can be disabled.
Power Consumption 12V=10W
Dimensions 132.2 (W) × 23.2 (D) × 10.2 (H) cm (52 1/16 × 9 1/8 × 4 inch)
Weight Approximately 11.2kg (24.7 lbs) (without batteries)

Casio Privia PX-S1000 Specifications

General

Polyphony	192 notes
Tones	18 built-in tones
Speakers	8W + 8W
Dimensions	1, 322 x 232 x 102 mm
Metronome	Yes
Keyboard	88 keys, scaled hammer action keyboard
Sound Source	Multi-Dimensional Morphing AiR Sound Source
Weight	11.2 kg
Power Source	AC adapter (included), 6 AA batteries (optional)
Touch Response	5 sensitivity levels
Effects	Reverb, Chorus, Brilliance, DSP
Bluetooth	Bluetooth Audio
Included Accessories	AC adapter, pedal unit (SP-3)
