Casio PX-150 Simple Manual

Note1 : Selecting the algorithms below add Part Volume and Part Pan to the above items.
ID DSP Algorithm
0000 Rotary
0001 Drive Rotary
2002 Compressor
2003 Limitter
After the same DSP line is assigned to different parts as described here, Reverb Send, Chorus Send, and
all DSP parameter settings are common to all parts. Note that changing the settings on any part will
also affect all of the other parts that are sharing the DSP line. To assign the parts to a different DSP
line, you need to change one of the parameters listed above before selecting the tone.
11 Channel Aftertouch
Format
Message Format: DnH vvH
n : MIDI Channel Number
vv: Value
Send This message is not sent by this Instrument.
Receive Receipt of this message adds modulation to the voice that is sounding. The modulation effect
differs according to the tone being used.
12 Pitch Bend Change
Format
Message Format: EnH llH mmH
n: MIDI Channel Number
ll: Value LSB
mm: Value MSB
Send Sent when the bend wheel is operated.(PX-350M)
Receive Receipt of this message changes the pitch of the currently sounding voice. Pitch bend change
sensitivity depends on the pitch bend sensitivity configured with RPN.
24

Casio PX-150 Specifications

General

Category	Digital Piano
Touch Response	3 sensitivity levels, Off
Sound Source	Multi-dimensional Morphing AiR
Maximum Polyphony	128 notes
Tones	18 built-in tones
Lesson Function	Part On/Off
Metronome	Yes
Duet Mode	Yes
Speakers	12cm x 2
Amplifiers	8W + 8W
Modes	Layer, Split
Songs	60 built-in songs
Tuning	A4 = 415.5Hz ~ 440.0Hz ~ 465.9Hz
Digital Effects	Reverb (4 types), Chorus (4 types)
Recorder	2 tracks, 1 song
Transpose	-12 to +12 semitones
Pedals	Included: SP-3, Optional: SP-33 (damper, soft, sostenuto)
Connections	Headphones (2), USB (to Host), Sustain Pedal
Power Supply	AC Adapter AD-A12150LW
Dimensions	1, 322 x 286 x 135 mm (without music stand)
Weight	11.1 kg (without music stand)
Keyboard	88-key, Scaled Hammer Action Keyboard II
