Casio PX-150 Simple Manual

A single session is concluded only when this Instrument returns an IPS (Individual Parameter Send)
in response to an IPR (Individual Parameter Request) from an external device, or when an external
device or this Instrument spontaneously sends an IPS. If this Instrument received an IPS, the value of
the applicable parameter is changed.
Depending on the function of a parameter, Individual Parameter Send may be used to issue a com-
mand to the Instrument or Individual Parameter Request may be used to check Instrument status
information.
16.1 Two-way Communication
16.1.1 Example : Data send in response to send request to the Instrument
Data Receiver Data Sender Operation
IPR -----> Send Request
<----- IPS Data Transfer
16.2 One-way Communication
16.2.1 Example : Data send to Instrument from external source
Data Sender Data Receiver Operation
-----> IPS Data Transfer
16.2.2 Example : Data send resulting from Instrument operation
Data Receiver Data Sender Operation
<----- IPS Data Transfer
35

Casio PX-150 Specifications

General

Category	Digital Piano
Touch Response	3 sensitivity levels, Off
Sound Source	Multi-dimensional Morphing AiR
Maximum Polyphony	128 notes
Tones	18 built-in tones
Lesson Function	Part On/Off
Metronome	Yes
Duet Mode	Yes
Speakers	12cm x 2
Amplifiers	8W + 8W
Modes	Layer, Split
Songs	60 built-in songs
Tuning	A4 = 415.5Hz ~ 440.0Hz ~ 465.9Hz
Digital Effects	Reverb (4 types), Chorus (4 types)
Recorder	2 tracks, 1 song
Transpose	-12 to +12 semitones
Pedals	Included: SP-3, Optional: SP-33 (damper, soft, sostenuto)
Connections	Headphones (2), USB (to Host), Sustain Pedal
Power Supply	AC Adapter AD-A12150LW
Dimensions	1, 322 x 286 x 135 mm (without music stand)
Weight	11.1 kg (without music stand)
Keyboard	88-key, Scaled Hammer Action Keyboard II
