Casio PX-150 Simple Manual

Part V
Parameter List
How to Read the Tables
• Number Base NotationSizeindicates the parameter value bit width as a decimal value. The bit
field position ofBlockas a decimal value. Values used in the explanations underDescription
are all decimal values, unless specified otherwise. Values other than those described above are all
hexadecimal.
• R/W field The R/W field indicates whether an IPR (Individual Parameter Request) read operation
or IPS (Individual Parameter Send) write op eration is enabled.
17 System Parameters
These parameters make it possible for an external device to check the status of the Instrument and for
an external device to command some operation of the Instrument.
17.1 System Information Parameter
This parameter is a container for system information.
Parameter ID R/W Block Size Array Min-Def-Max Description
Model 0000 R 000000 7 01 00-00-7F 0...PX-150
1...PX-750
2...AP-250
3...PX-850
4...PX-1200GP
5...AP-450
6...PX-350M
7...reserved
8...reserved
9...AP-650M
10...reserved
18 Setup Parameter
Setup Parameters put a device into the setup mode.
18.1 MIDI Parameter
Parameter ID R/W Block Size Array Min-Def-Max Description
Midi Device Id 0070 R/W 000000 7 01 00-7F-7F 0-127
36

Casio PX-150 Specifications

General

Category	Digital Piano
Touch Response	3 sensitivity levels, Off
Sound Source	Multi-dimensional Morphing AiR
Maximum Polyphony	128 notes
Tones	18 built-in tones
Lesson Function	Part On/Off
Metronome	Yes
Duet Mode	Yes
Speakers	12cm x 2
Amplifiers	8W + 8W
Modes	Layer, Split
Songs	60 built-in songs
Tuning	A4 = 415.5Hz ~ 440.0Hz ~ 465.9Hz
Digital Effects	Reverb (4 types), Chorus (4 types)
Recorder	2 tracks, 1 song
Transpose	-12 to +12 semitones
Pedals	Included: SP-3, Optional: SP-33 (damper, soft, sostenuto)
Connections	Headphones (2), USB (to Host), Sustain Pedal
Power Supply	AC Adapter AD-A12150LW
Dimensions	1, 322 x 286 x 135 mm (without music stand)
Weight	11.1 kg (without music stand)
Keyboard	88-key, Scaled Hammer Action Keyboard II
