14.1.2 Master Balance
Format
Message Format: F0H 7FH 7FH 04H 02H llH mmH F7H
ll: Value LSB (Note1)
mm: Value MSB (Note1)
Note1 : For information about the relationship between setting values and send/receive values, see  25.6 Pan Setting
Value Table  in  VII Setting Values and Send/Receive Values .
Send This message is never sent.
Receive Receipt changes the Master Pan parameter. Note that the Master Pan parameter cannot be
changed with an Instrument operation
14.1.3 Master Fine Tuning
Format
Message Format: F0H 7FH 7FH 04H 03H llH mmH F7H
ll: Value LSB (Note1)
mm: Value MSB (Note1)
Note1 : For information about the relationship between setting values and send/receive values, see  25.7Master Fine
Tuning Setting Value Table  in  VII Setting Values and Send/Receive Values  of this document.
Send This message is sent when the tuning setting is changed.
Receive Receipt changes the Master Fine Tune8 parameter of Patch.
14.1.4 Master Coarse Tuning
Format
Message Format: F0H 7FH 7FH 04H 04H llH mmH F7H
ll: Send:00H, Receive:Ignored
mm: Value MSB
Send This message is never sent.
Receive Receipt changes the Patch Master Coarse Tune parameter.
14.1.5 Reverb Parameter
Format
Message Format: F0H 7FH 7FH 04H 05H 01H 01H 01H 01H 01H ppH vvH F7H
pp: Parameter
vv: Value
26

Casio PX-150 Specifications

General

Category	Digital Piano
Touch Response	3 sensitivity levels, Off
Sound Source	Multi-dimensional Morphing AiR
Maximum Polyphony	128 notes
Tones	18 built-in tones
Lesson Function	Part On/Off
Metronome	Yes
Duet Mode	Yes
Speakers	12cm x 2
Amplifiers	8W + 8W
Modes	Layer, Split
Songs	60 built-in songs
Tuning	A4 = 415.5Hz ~ 440.0Hz ~ 465.9Hz
Digital Effects	Reverb (4 types), Chorus (4 types)
Recorder	2 tracks, 1 song
Transpose	-12 to +12 semitones
Pedals	Included: SP-3, Optional: SP-33 (damper, soft, sostenuto)
Connections	Headphones (2), USB (to Host), Sustain Pedal
Power Supply	AC Adapter AD-A12150LW
Dimensions	1, 322 x 286 x 135 mm (without music stand)
Weight	11.1 kg (without music stand)
Keyboard	88-key, Scaled Hammer Action Keyboard II
