Casio V-R200 User Manual

– 12 –
V-R200 / VER.2
DIAGNOSTIC OPERATION
1.
HARDWARE TEST
1-1. List of test items . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 13
1-2. Installing the Test Application
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 14
1-3. About the Test Application
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 15
1-4. Touch panel calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 16
1-5. Test Method
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 17
1-6. Checking and Registering the Serial Number
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 29
1-7. Uninstalling the Test Application
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 30
2.
UPDATING the OS
2-1. Checking the Version
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 31
2-2. Updating Method
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 31
Repair Information
When the main PCB is replaced with a spare part one.
• Since an OS is already installed on the spare part main PCB, update the OS to an appropriate
version as required.
Refer to: Diagnostic operation
2. UPDATING the OS
• Write the serial number.
Refer to: Diagnostic operation
1-6. Checking and Registering the Serial Number
When the IOC PCB is replaced with a spare part one.
• Firmware is already installed on it.
• The fi rmware version is confi rmed at power on and, if necessary, it is automatically updated.
• UUID setting is not required.
When the CASE ASSY/FRONT is replaced with a spare part one.
• Carry out the touch panel calibration.
Refer to: Diagnostic operation
1-4. Touch panel calibration
To carry out the Diagnostic operation, a dedicated application is needed to be installed
beforehand.
NOTE: After completion of the test, make sure to uninstall the test application.

Casio V-R200 Specifications

General

Brand	Casio
Model	V-R200
Category	Cash Register
Language	English
