Screws
There are several kinds of screws. Be sure to use the
correct type of screws when reassembling.
It is advisable to sort the screws as shown on the right
after removing them.
S1
( φ : 3mm, L: 10mm)
S2
( φ : 3mm, L: 5mm)
S3
( φ : 3mm, L: 8mm)
10 mm
3 mm
5 mm
3 mm
8 mm
3 mm
S4
( φ : 3mm, L: 8mm)
S5
( φ : 3mm, L: 5mm)
S6B (S6)
( φ : 3mm, L: 8mm)
8 mm
3 mm
5 mm
2 mm
8 mm
3 mm
S7
( φ : 3mm, L: 8mm)
S8
( φ : 2.5mm, L: 6.2mm)
S9
( φ : 2mm, L: 6mm)
8 mm
3 mm
6.2 mm
2.5 mm
6 mm
2 mm
S10
( φ : 3mm, L: 10mm)
10 mm
3 mm
