– 65 –
V-R200 / VER.2
PARTS LIST
1: V-R200-BD 2: V-R200-BD-WE 3: V-R200-U 4: V-R200-U-WE 5: V-R200-C
12345
MAIN UNIT
N 1 10540722 CASE ASSY/UPPER/BK RJE504576*001V01 1 1 1 C
N 1 10540723 CASE ASSY/UPPER/WE RJE504576*002V01 1 1 C
S1
SCREW (3x10) S-PADSMA-3X10Z3 22222X
N 1-1 10540717 COVER/PRINTER/BK RJE504693*001V01 1 1 1 C
N 1-1 10540718 COVER/PRINTER/WE RJE504693*002V01 1 1 C
N 1-2 10529377 ARM/PLATEN RJE504567-001V01 11111C
N 1-3 10465445 LEVER/EJECT RJE504177-001V01 11111C
N 1-4 10540724 LABEL/PUSH RJE503907-003V01 11111X
N 1-5 10529371 MASK/PRINTER RJE504584-001V01 11111C
S4
SCREW (3x8) S-BDPT-3X8Z3 22222X
1-6 10413753 GEAR ASSY TK-RJE503868*001 11111B
S4
SCREW (3x8) S-BDPT-3X8Z3 22222X
S10
SCREW (3x10) S-BDPT-3X10Z3 22222X
N 2 10525695 PRINTER/THERMAL CAPD347J-E 11111Awith Cutter
S2
SCREW (3x5) S-BDMA-3X5Z3 22222X
S5
SCREW (2x5) S-PAMA-2X5Z3 22222X
N 3 10525699 SHEET/BLIND RJE504607-001V01 22222A
N 4 10540719 DISPLAY ASSY/REAR/BK RJE504575*001V01 1 1 1 C
N 4 10540720 DISPLAY ASSY/REAR/WE RJE504575*002V01 1 1 C
N 5 10529378 COVER/IF/BK RJE504555-001V01 1 1 1 X
N 5 10529379 COVER/IF/WE RJE504555-002V01 1 1 X
S2
SCREW (3x5) S-BDMA-3X5Z3 11111X
6 10406965 SW SUBASSY/TILT RJE503884*001V01 1 1 1 B
6 10436482 SW SUBASSY/TILT RJE503884*002V01 1 1 B
N 7 10540726 PCB ASSY/E843-E63 RJE504582*001V01 11111B
N 8 10540725 PCB ASSY/E843-PR RJE504579*001V01 11111B
S2
SCREW (3x5) S-BDMA-3X5Z3 11111X
N 9 10540721
PCB ASSY/E843-IOC
W/CHASSIS
RJE504692*001V01 11111A
S2
SCREW (3x5) S-BDMA-3X5Z3 88888X
S7
SCREW (3x8) S-BD-PT-3X8Z3 44444X
N 10 10529382 CHASSIS/BOTTOM RJE504541-001V01 11111X
S2
SCREW (3x5) S-BDMA3X5-Z3 77777X
S7
SCREW (3x8) S-BD-PT-3X8Z3 44444X
N 11 10529384 PLATE/BLIND RJE504583-001V01 11111X
S7
SCREW (3x8) S-BD-PT-3X8Z3 22222X
12 10414065 PAD/RUBBER RJE503879-001V02 33333X
N 13 10540737 PAD/RUBBER/E843 RJE504592-001V03 11111X
14 10413634 BLIND/CN RJE503920-001V01 11111X
R RemarksN Item Code No. Parts Name Specification
Qt'y
To Next Page
