Mounting the computer
1
Mount the bracket
•
When mounting on stem
•
When mounting on handlebar
When mounting the bracket on a handlebar,
adjust the angle of the bracket so that
the back of the computer faces the speed
sensor when the computer is attached.
Stem
Handlebar
Nylon tie
Nylon tie
Bracket
Bracket
Correct
Wrong
Doublesided tape
Doublesided tape
Bracket Doublesided tape
Speed sensor Sensor rubber pad Nylon tie
(x 4)
Magnet
Cut
Cut
Pull tight
Pull tight
