Catrike MAX - Handlebars

REV 12.18.24 Pg.16 MAX
TALL HANDLEBAR ASSEMBLY RIGHT
SHIFTER SCREW
TORQUE 5Nm (40INLBS)
HAND REST PAIR (RIGHT)
# BC1249
HANDLEBAR LOWER HORIZONTAL SUPPORT - RIGHT
# BC1004
ASSIST BAR RIGHT
11 SPEED REAR BAR END SHIFTER
FOAM GRIP
# 129
LONG HANDLEBAR - RIGHT
# BC1292
FOR BAR END SHIFTER
ADJUSTMENT VISIT
SRAM SERVICE HUB
LOCKING BRAKE LEVER
LOCKOUT BUTTON FACES OUTWARDS
FOR ASSIST BAR
ADJUSTMENT
VISIT PAGE 15
