Catrike MAX - Adjustable Seatback

REV 12.18.24 Pg.25 MAX
ADJUSTABLE SEATBACK FORK ASSEMBLY
M8X16 BARREL (2x)
M8 NYLON WASHER .5” OD x .03” THICK (2x)
ADJUSTABLE SEAT BRACKET (2x)
# BC1200
NESTING FEATURES FACING OUTSIDE OF TRIKE
M6 WASHER (2x)
8x8.5MM NORGLIDE BUSHING (2x)
M6x10 BHCS (2x)
MEDIUM THREADLOCKER
