Catrike MAX - Page 25

REV 12.18.24 Pg.24 MAX
STRAIGHT ADJUSTABLE SEATBACK ASSEMBLY
M6x10 BHCS
MEDIUM THREADLOCKER
M8 NYLON WASHER .75” OD x .062”THICK
8x8.5MM NORGLIDE BUSHING
M8x22 BARREL
M6 WASHER
STRAIGHT SEATBACK
LEFT SIDE SHOWN,
RIGHT SIDE MIRRORED
TRIKE FRAME
LEFT
RIGHT
