BOOM INSERTION
VIEW FROM
UNDERNEATH
TRIKE
MINIMUM BOOM INSERTION IS
6” FROM THE FRONT OF THE
TRIKE.
IF BOOM POSITION IS PAST THIS
POINT, SEVERE DAMAGE CAN
OCCUR TO THE FRAME
PEACE BOOM
FRONT OF TRIKE
