Audio Connection
Connection method of CAYIN CS-100A with other audio equipments take pictures below for your reference.
Wrong connection
Right connection
NOTE:
• Please refer to the manual s of other connected equipments during the installation.
• Do not insert the power cord in to the main socket before all other equipments are well connected.
• R refers to right channel while L represents left channel.
• Please take the right guidance for connection as wrong connection may cause noise, low-grade
function or damage.
• Do not fasten signal cable together with power cable and speaker cables. It will worsen the acoustic
fidelity.
LEFT OUTPUT
RIGHT OUTPUT
INPUT
LINE2
LINE1
LINE3
PRE- IN
TUBE SEL.
EL34
KT88
MODEL : CS - 100A
SER. NO. :
VACUUM TUBE INTEGRATED AMPLIFIER
ZHUHAI SPARK ELECTRONIC EQUIPMENT CO.,LTD.
SUB OUT
OUTPUT
2
1
To audio
output terminal
To Next Page
