4
Specifications
Power Output
TR:50W+50W (RMS Triode mode)
UL:80W+80W (RMS Ultralinear mode)
Frequency Response
8Hz~75kHz (-3dB)
THD
1%(1kHz)
S/N Ratio
92dB
Input Sensitivity
450mV (Integrated)
1300mV (PRE-IN)
Input Impedance
100kΩ
Output Impedance
4Ω, 8Ω
Input Terminals
LINE1,LINE2,LINE3,PRE-IN
Output Terminals
SUB OUT
WDH
420mm×394mm×200mm
Tube
KT88(EL34)×86SN7GTB×112AU7EH×212BH7EH×2
Net Weight
29.5kg
Max Power Consumption
480W
Working Condition
Temperature0℃~40Moisture20%80%
Storage Condition
Temperature-20℃~70Moisture20%90%
To reduce the risk of electric shock, do not remove the cover.
No user serviceable parts inside. Refer servicing to qualified service
personnel.
To reduce the risk of fire or electronic shock, do not expose the unit to
rain or moisture.
The lightning flash with arrowhead symbol is intended to alert user to the presence of uninsulated
“dangerous voltage” within the product's enclosure that may be of a risk shock to persons.
The exclamation point is intended to alert user to the presence of important operation and maintenance
(servicing) instructions accompanying the appliance.
