DISTRIBUITION BOX “DS520-AN”
PROTECTION FUSES
14) 20A fuse lights “B”for circuit .
16) AES fridge connection; It is a bridge, which
excludes the 3 way function fridge and is used to
connect the AES fridge directly to the B2.
12) 10A fuse the water pumpfor .
10) 3A fuse spark ignitions for for the fridge, oven &
stove, it is connected directly to the leisure
battery (B2).
11) Not actived.
17) Output + for the control of the auxiliary relays
(e.g. motorized step, AES fridge, electric water
discharge valve, electric antenna motor, etc.)
which works only when the engine is started.
which works only when the engine is started.
13) 20A fuse lights “A”for circuit .
15) 3A fuse from ignition to protect the OUT D+
simulated exit.
2) 3A .Spare
3) 15A fuse the RH auxiliary for roof fans etc (if
fitted).
4) 20A TV socketsfuse for and TV antenna (if
fitted).
5) 15A fuse the RH auxiliary 2for range hood and
water pump switch (if fitted).
nd
6) 30A fuse 12V fridgefor element (when
connected through bridge 16 it turns off
automatically when engine is off).
1) 5A fuse to give power the AUX auxiliary exit
( )awning light , turns automatically off when
engine is on.
8) 20A fuse AUX for the (i.e. Gas detector, radio
memory etc), it is connected directly to the
leisure battery (B2). (constant supply)
9) 25A fuse motorized step , it is
connected directly to the leisure battery (B2).
for the (if fitted)
7) 10A fuse for Heater/Hot Water System (HWS).
