7
FUNCTIONS
CHASSIS BATTERY ALARM (B1)
Fuses
greater .
are automatically reactivated when voltage is
than 13 5V.
It is possible to reactivate all for one minute by
pressing the on/off button (ref. on control panel)
fuses
5 .
When the chassis battery voltage drops down to 12V,
the Chassis the
symbol ref. 16 starts blinking.
Battery Discharge alarm goes on and
MINIMUM VOLTAGE CONTROL (BATTERY
PROTECTION)
When the leisure battery voltage drops down to
10.5V, the eisure ischarge alarm
automatically , the symbol ref. 17 starts blinking
and you hear two short beeps. Alarms go off when the
voltage gets over 12.5V
L Battery D goes
on
.
LEISURE BATTERY ALARM (B2)
When leisure battery voltage drops down to 11.5V the
L Battery R goes on, eisure eserve alarm automatically
the symbol ref. 17 starts blinking and you hear a short
beep.
Alarm goes off when the voltage gets over 12.5V.
The electronic battery protection device cuts off the
12V when leisure battery reaches 10V and
disables: pump, lights, ,
fuses
awning light
and stove.
exit RH“ ”, TV
sockets
Symbol ref. 15 is the visual alarm signal.
The control panel automatically turns off with a
voltage lower than 9.5V.
This device doesn’t control the the 12V users
connected directly to the leisure battery B2 .
ment- Measure is carried out as difference
between charging and discharging currents: a
positive value indicates a charging current, a
negative value indicates a discharging current.
ment- Measure range is: -40A ÷ +40A.
- It measures the current of the leisure battery,
users’ consumption and recharge through
battery charger, engine alternator and solar
panels.
The ammet er is inside the DS520 AN module.-
AMMETER
To measure the charging of a sole source (battery
charger, alternator or solar panels), turn off all
items and other charging sources.
An electronic device switches off the awning light
when engine is turned on.
To measure the consumption of a sole user,
disconnect all charging sources and turn off all
unused items.
AWNING LIGHT AUTOMATIC TURN OFF
DIGITAL CLOCK
ALARM CLOCK
To set and activate/deactivate the alarm clock see
“SETTING”.
To reset alarm press any test button; there is no
delayed alarm!
To set clock see “SETTING”.
TEMPERATURE
- Both int. and ext. temperatures have a sensor, which
is placed inside or outside of the vehicle.
TWILIGHT FUNCTION
NOTE: before replacing the fuse find out the problem
that determined the intervention of the protection
(blown fuse) it may be necessary to have a
qualified technician assist
and fix it,
.
The lighting of the LED signals that the fuse is broken
and it is necessary to replace it with another fuse with
the same value. The alarm is activated only when the
control panel is on and the user related to the fuse is
switched on.
- The precision of the temperature value is ±1°C.
Under each fuse is positioned a red LED.
In a “night” situation, a sensor positioned near the
display causes the intensity of the LED backlight to
automatically be reduced to the level preset by the
user (to set see SETTING).
BROKEN FUSE ALARM
EN
