6
MAIN VISUALIZATIONS
6) Internal temperature digital indicator.
7) Clock digital display.
1) . It indicates that the engine is on
8) It displays the setting menu.
2) It displays that the battery parallel is on when
engine is on.
5) External temperature digital indicator.
3) It displays that the chassis battery recharging
unit is on.
4) It indicates that the 2 0V battery charger is
on
4
.
16) It displays that the c battery has
run down.
hassis (B1)
9) It displays that the tones are off.
17) It displays that the leisure battery has run
down.
(B2)
15) It displays the minimum voltage device is on.
14) It displays that the waste water tank is full.
1 )2 “ ”B2 leisure battery status display.
10) It displays that alarm clock is set.
1 )1 Fresh water tank status display.
1 )3 It displays that the water tank is empty.fresh
21 3 4
6
5
7
8
9 10
12
11
13 14 15 16 17
EN
