CBE PC380-KT - Earth Connections; Leisure Battery Connection; 12 V Exit Connection; Chassis Battery Connection

14
EARTH
To connect to the mains' earth.
28)
EARTH
To connect to the negative pole of the battery or to the chassis of the
vehicle.
leisure
29)
LEISURE BATTERY
To connect to the pole of the batterypositive leisure .
30)
12V EXIT
To connect to the positive pole (battery charger, solar regulator).
31)
+ OUT 12V
+ B2
- B2
CHASSIS BATTERY
To connect to the positive pole of the chassis battery.
32)
+ B1
EN
