Use the salt tester supplied with the LIMPIDO to check that the salt content is correct.
Please refer to the tester instructions before use.
INSTALLATION
Hydraulic installation
Install the cell and the flow detector according to one of the following layouts:
Side view
Bottom view
Flow
detector
Cell
Cell
Discharge
Intake
Flow
detector
In line installation
The bypass installation is necessary when the inline flow exceeds 22m
3
/h.(see below).
