Chapter 7: Specifications
Model
4CH 8CH
Video System NTSC / PAL(Optional)
Compression Format
Video:H.264 / Audio:8kHz*16bit ADPCM
Video Output 4-CH BNC Input/ 2-CH BNC Output / 1-VGA output
8-CH BNC input/2-CH BNC output / 1-
VGA output
Audio I/O 4-CH RCA audio Input / 2-CH RCA audio Output
1-CH RCA audio input/ 1-CH RCA audio
output
Display Resolution
D1:704×576(PAL) 704×480 (NTSC)
Frame rate
Single CH PAL:25 fps ,NTSC:30 fps
Recording Resolution
PAL: CIF(352*288), HD1(704*288) D1 (704*576)
NTSC:CIF(352*240),HD1(704*240) D1 (704*480)
PAL:CIF(352×288)
NTSC:CIF(352×240)
Recording Frame Rate (shared)
PAL:25 fps@D1, 50 fps@HD1, 100 fps@CIF
NTSC:30 fps@D1, 60 fps@HD1,120 fps@CIF)
PAL:200 fps@CIF
NTSC:240 fps@CIF
HDD
1 SATA HDD, up to 1024GB;USB removable HDD
Video Mode
Always / schedule / manual /motion detection / sensor triggered
Record Pack Time
15/30/45/60min
Video backup
USB flash disk / removable HDD,USB Burner, Network backup to AVI File Format
Playback Mode
PLAY /SLOW /FWD/Frame by Frame
Alarm I/O 4-CH alarm inputs, 1-CH alarm output 8-CH alarm inputs,1-CH alarm output
Alarm Type Motion/ sensor triggered/Video loss/HDD Space/HDD Loss
PTZ Control Built-in RS-485 port, supports PELCO-P & PELCO-D
USB 2.0 Port
Supports USB mouse,removable HDD,USB flash drive to backup to AVI file and upgrade
system
Ethernet One RJ-45 10M/100M self-adaptable Ethernet interface
Network Protocol Supports TCP/IP, DHCP, UDP, DDNS, PPPOE network Protocol
Network Function
Support preview live display remotely via mobile phone and real time monitoring via IE-based
browser and/or network, and support parameter setting of DVR remotely
.
Power consumption
10~15W (exclude HDD)
Power Adapter DC 12V / 3A DC 12V / 3A
Working Temperature
50°F to 104°F (10℃ to 40℃)
Working humidity
10%~90%
Dimension (W x D x H)
11.75 x 9 x 2 in (300 × 220 × 47 mm)
List 7-1
