CCTV Discover 4CH - 8-CH Front Panel (Details Please Refer to the Real Product)

User Manual
4
2.1.2 8-CH Front Panel (Details please refer to the real product)
1
Power Switch 11 PAUSE: Pause / Frame Play
2
PWR: PWR Indicator 12 PLAY: Play
3
IR receiver for Remote Control 13 FWD: Play Forward / Move Right
4
HDD: HDD Indicator 14 STOP: Stop Playback; Stop manual Recording
5
SEARCH: Recording Search 15 REC: Manual Recording
6
MUTE: Audio Mute key 16 MENU/ESC: Menu / Escape
7
CH-: Switch to previous channel 17 UP: Move Up
8
CH+: Switch to next channel 18 SEL/EDIT: Select / Edit
9
ALL: Preview all channels 19 DOWN: Move Down
10
REW: Rewind / Move Left 20 PTZ: Move to PTZ control mode
