CDA CI931 Manual For Installation, Use And Maintenance

Cleaning the Filter
s Clean the accessible filter if the drain pump is blocked by any
foreign objects.
s Open the kickplate cover with the aid of a coin and by gently pulling open
(Figure 36).
s Place a container under the drain pump filter to collect any water that
comes out of it (Figure 37).
s Remove the drainpipe, place it on the container and open the cover. Water
will start to come out.
s Half- or quarter-turn the filter to the left and water will start to come out
(Figure 37).
s When all the water has drained out of the washing machine, turn the filter
several times until it can be completely removed by gently pulling on it
(Figure 38).
s Remove the objects or fluff caught in the filter or the drain pump
(Figure 39).
s Put the filter and the filter cap back in place.
To avoid risk of scalding, do not carry out this operation when the
wash water is at a temperature of over 30ºC.
Cleaning the Outside of the Washing Machine
s The outside of the washing machine should be cleaned with warm soapy
water or a gentle cleaning agent. Do not use abrasive cleaning products
or solvents.
s It should then be thoroughly dried with a soft cloth.
Wipe any detergent spills immediately to minimise the risk of
damage to the cabinet of your washing machine.
fig. 36
fig. 37
fig. 38
fig. 39
19

CDA CI931 Specifications

General

Door hinge	Left
Product color	White
Appliance placement	Freestanding
Washing capacity	6 kg
Maximum spin speed	1200 RPM
Number of drying programs	15
Washing class	A

Weight and Dimensions

Depth	545 mm
Width	596 mm
Height	818 mm
