CDA CI931 Manual For Installation, Use And Maintenance

Unpacking the Washing Machine
s Remove the base, corner protectors and top cover (Figure 1).
Removing the Transit Bolts
s Remove the screws holding the plastic covers to the back of the
washing machine (Figure 2 and 3).
s Loosen and remove the 3 transit bolts (Figure 3).
s Cover the holes with the plastic covers you have just removed (Figure 2).
Do not throw the transit bolts away. If you need to move the washing
machine after installation you should first replace the transit bolts.
fig. 1
fig. 2
fig. 3
fig. 4
3

CDA CI931 Specifications

General

Door hinge	Left
Product color	White
Appliance placement	Freestanding
Washing capacity	6 kg
Maximum spin speed	1200 RPM
Number of drying programs	15
Washing class	A

Weight and Dimensions

Depth	545 mm
Width	596 mm
Height	818 mm
