CDA CI931 Manual For Installation, Use And Maintenance

Connecting to the Mains Water Supply
The water supply hose is located inside the drum.
s Connect the bent end of the hose to the threaded inlet of the
electrovalve located at the rear of the washing machine.
s Connect the other end of the hose to the water inlet. Then securely
tighten the connecting nut.
The drain hose must be securely fastened to the outlet to prevent
any risk of the drain hose becoming detached and causing flooding.
The washing machine must be connected to the mains water supply,
using the new supply hoses supplied with the appliance. Do not use
water supply hoses that have been used previously.
For your washing machine to work properly, the mains water
pressure must be between 0.05 and 1MPa (0.1 - 10 bar).
Drainage Connection
s It is recommended that you have a fixed drainage outlet 50 to 70 cm
from the floor.
s Avoid the drain hose being too tight, kinked or restricted.
s The water outlet can either be connection to a water drain or to a sink
outlet spigot. This connection should be a minimum of 50cm and a
maximum of 110cm from the floor. The drain hose should be no longer
than 4m in length to ensure good performance from the dishwasher.
s After connecting the water supply, check to ensure there are no leaks.
fig. 5
fig. 6
4
fig. 4

CDA CI931 Specifications

General

Door hinge	Left
Product color	White
Appliance placement	Freestanding
Washing capacity	6 kg
Maximum spin speed	1200 RPM
Number of drying programs	15
Washing class	A

Weight and Dimensions

Depth	545 mm
Width	596 mm
Height	818 mm
