Final installation checks
Run a quick test cycle to make sure the appliance fills, turns, drains
etc. with no issues. If you encounter any issues, ensure that the install
is as close to the below images as possible, depending on the install.
Ensure that no hoses are kinked, water is on and sink spigots are cut,
if applicable.
800mm - 1000mm
Power
outlet
Waste
Waste
200mm minimum
bend radius from
valve. Ensure the
inlet hose is free
from kinks.
Water
supply
Valve
Cut/open
spigot
Waste
Water
supply
Valve
200mm minimum
bend radius from
valve. Ensure the
inlet hose is free
from kinks.
150mm min.
