CDA Oven - 2.4 Changing the Power Cord

8
••
——
The power cable (H05 RR-F, H05 RN-F ou H05 VV-F) must be of sufficient length to be connect-
ed to the build-in oven while it sits on the floor in front of the cabinet.
To do this the appliance must be disconnected from the electrical network:
——
Open the inspection flap located at the lower right of the back cover by unscrewing the two
screws, then pivot the inspection flap.
——
Strip 12 mm along each wire of the new power cable.
——
Carefully twist together the strands.
——
Loosen the screws from the terminal board and remove the power cord to be replaced.
•
Introduce the power cable through the side of the cover in the cable clip located to the right of
the terminal board.
——
All the strands of the electricity wires must be captured under the screws.
——
The phase wire on the L terminal.
——
The green-yellow coloured ground wire should be connected to the terminal .
——
The neutral conductor (blue) on the N terminal.
——
Screw down tightly the screws on the terminal board and check the connection by pulling on each
wire.
——
Attach the cable with the cable clip located to the right of the terminal board.
——
Close the inspection flap using the two screws.
Warning
WWee ccaannnnoott bbee hheelldd rreessppoonnssiibbllee ffoorr aannyy aacccciiddeenntt rreessuullttiinngg ffrroomm aann iinneexxiisstteenntt,, ddeeffeeccttiivvee
oorr iinnccoorrrreecctt
ggrroouunndd lleeaadd..
IIff tthhee eelleeccttrriiccaall iinnssttaallllaattiioonn aatt yyoouurr rreessiiddeennccee rreeqquuiirreess aannyy cchhaannggeess iinn oorrddeerr ttoo hhooookk
uupp yyoouurr
AApppplliiaannccee,, ccaallll uuppoonn aa pprrooffeessssiioonnaall eelleeccttrriicciiaann..
IIff tthhee oovveenn mmaallffuunnccttiioonnss iinn aannyy wwaayy,, uunnpplluug
g tthhee aapppplliiaannccee oorr rreemmoovvee tthhee ffuussee ccoorrrreessppoonnddiinngg
ttoo tthhee sseeccttoorr tthheerree tthhee oovveenn iiss hhooookkeedd uupp..
