CDI CD42-T1A - QUICK-START; Prepare Transmitter

22 Hz ELECTROMAGNETIC TRANSMITTER USER GUIDE
Page 3 of 52
CD42ͳTͳSERIES QUICKͳSTART
1. PREPARE TRANSMITTER
ALL MODELS: Remove End Cap See PRESSURE WARNING, previous page
T0, T1, T1A/T1AHP/T1AVHP, T2 MODELS:
Remove Carousel
Confi gure Pulse Pa ern
T0:
T1/T1A/T1AHP/T1AVHP:
T2:
NOTE: The next few pages are a quick-reference guide to help you set up your CD42-T Series
transmiƩ er in a Ɵ mely manner. It is highly recommended that you familiarize yourself with
the rest of this User Guide (beginning on pg. 7) at the earliest opportunity.
Standard
Skip-One
Con nuous
Standard Skip-One Con nuous
:
:
T
T
2:
Standard Skip-One Con nuous
