22 Hz ELECTROMAGNETIC TRANSMITTER USER GUIDE
Page 4 of 52
CD42ͳTͳSERIES QUICKͳSTART
1. PREPARE TRANSMITTER CONT.
T3 MODEL:
Remove Ba eries
Confi gure Pulse
Pa ern
T4 MODEL: All T4 model transmi ers are programmed at the factory.
(There are no dip switches)
T0, T1, T1A/T1AHP/T1AVHP, T2 MODELS:
T0: Load Carousel with six (6)
N-Cell alkaline ba eries
T1, T1A/T1AHP/T1AVHP, T2: Load Carousel
with six (6) AA-Cell alkaline ba eries
T3 & T4 MODELS:
T3: Load single CR-123 ba ery, posi ve (+) end fi rst.
T4: Load two (2) CR-123 ba eries, nega ve (-) end fi rst,
posi ve (+) end UP.
ALL MODELS: Replace End Cap
TER
CONT
.


ery, posi ve
(
+
)
end fi rst
.
e
ri
i
es negave ( ) end first
NOTE: it is good prac ce to always install
new ba eries prior to deployment.
NOTE: Unless transmi er is fi  ed with CD42-SWX
pressure-ac va on switch or factory-confi gured for DELAY ON
opera on, it is ac ve when cap is replaced.
Standard
Skip-One
re Pu
ulse
