1] PRODUCT PRESENTATION
Thank you for buying our products and for the confi dence you placed
in our company.
ARD12 BS60
Recommended
power supplies
Stainless steel.
Braille keys.
Weatherproof IP54.
3 relays + 2 leds.
Surface mount.
Installation with Diax
®
screw.
Varnish coated PCB.
100 user codes.
 Audibleandvisualfeedback.
 PCBprotectedagainsthumiditybyvarnish
coating.
 Request-to-enter(Trade)canbeoperated
fromthe0digit.
 D imensions( LxWxD ):125x100x65mm.
 Inputvoltage:12Vto24Vac
12Vto48Vdc.
 Consumption:140mA.
IP54
-20°C to +50°C
Certifi cation CE
HIGHRESISTANCE
TOVANDALISM
WEEE
2] REMINDERS AND RECOMMENDATIONS
Recommended power supplies
-Therearetwosuitablepowersupplies
fortheenclosedkeypad:
ARD12andBS60
-Separatepowersupplyforcontrolcomponents.
Mounting recommendations
Mountthekeypadonaflatsurfacetoavoid
anyvandalismandtoensurethebestmounting.
Security advice
Forsecurityadvicereasons,changethefactory
defaultmastercode.Whenselectingamastercode
andusercodeavoidsimplecodes(example:3 4 5 6 7).
Back EMF protection
Tosecurethesystemfrombackelectromagnetic
eldsdonotforgettoinsertthevaristor
inparallelwiththelock.
