INSTALLATION MANUAL
CBB
Self-contained Keypad - braille keys
5] WIRING DIAGRAM
Terminals Description
V
Inputvoltage12Vto24Vac
or12Vto48V dc
V
Inputvoltage12Vto24Vac
or12Vto48V dc
P1 Relay1Request-to-Exitinput
M CommoninputforP1andH1
H1 Clockswitch
N0 Relay2N/Ccontact
C2 Relay1common
N0 Relay1N/Ccontact
C1 Relay1common
NC Relay1N/Ocontact
N0 Relay3N/Ccontact
C3 Relay3common
This product is supplied with a varistor.
Itshouldbemountedontheterminalofelectricrelease(electromagneticlock,solenoidbolt,etc.)controlled
bythedevice.Ifthisdevicecontrolsmorethanoneelectronicrelease,theneachlockshouldbetted
withavaristor.Thevaristorcontrolstheoverloadproducedbythestrikecoil-backemf.Itisrecommended
touseaseparatepowersupplywhenusingaShearLockMagnet.
Input Voltage
12Vto24Vac
or12Vto48Vdc
230V
Input Voltage
12Vto24Vac
or12Vto48Vdc
230V
Strike Varistor
P2 :Reset P3 :Enable/disableusercode
modicationbyuser
ST1 :Audiblefeedbackjumper
Removetodisableaudible
feedback
Magneticlockorfail-safestrike
Failsecurelockingdevice
