3] MOUNTING KIT
DIAX
®
screw
(M5x16)
DIAX
®
screw
spanner
(ODIAX tool)
05D 680K
Varistor
CBB
1 1 1
4] MOUNTING INSTRUCTIONS
Onceyouhavemadesurethatthemountingkitiscompleteandthatyoupreparedthecables
oftheCBBkeypadthenyoucanproceedandmounttheproduct.Makesurethatyouhave
all theappropriate tools (drill, screw driversand a meter tape...) and follow the mounting
instructionsoffortheCBBkeypad.
Take the fl ush casing to measure and
mark the mounting holes. Then drill the 4
mounting holes and the wiring access area.
1
Mount the back casing of the CBB
and the electric cable from the wiring
access area.
2
Finally Mount the CBB with the DIAX
®
screw.
3
