CEBORA S.p.A. 23
5 - ELECTRICAL DIAGRAMS
5.1
- Power source art. 947 : see file SCHE947.pdf enclosed at the end of the manual.
5.2 - Waveforms.
5.2.1 - HF command pulse (par. 3.3.5).
5.2.2 - Open-circuit output voltage for the duration of approximately two seconds
(maximum pilot arc time) (par. 3.3.6, 3.3.7).
5.2.3 - Pilot arc current signal (par. 3.3.6, 3.3.8).
3.302.167 25/06/04
