2.2 Specification
Model DID-05 DID-4 DIW-15 DIW-20 DIW-75 DIW-120
Accuracy guarantee
range
mN・m
2.0～500
N・m
0.020～4 0.20～15 0.20～20 0.20～75 2.0～120
kgf・cm
0.020～5 0.20～40 2.0～150 2.0～200 2.0～750 20～1200
lbf・in
0.020～4.5 0.20～35 2.0～130 2.0～174 2.0～651 20～1040
Accuracy
±0.5%
(499 digit or less ±3digit)
±0.5%
(1
±3digit)
±0.5%
(499 digit or less ±3digit)
±0.5%
(1
±3digit)
Accuracy ±0.5% (499 digit or less ±3digit)
Display The 4 figures digital display of LCD
The measurement direction
CW-CCW (right and left)
Measurement Mode P-P (peak to peak) / T-R (track) / P-D (peak-down) / C (Real-time Output)
High - low limits judging function
High and low value is measurement within the limits, and can be set up.
Results judgment
It can perform results judgment within the setting.(in P-P mode)
It confirms with lamp lighting or a buzzer.
The Maximum, the minimum,
and the average value display
It displays the maximum, the minimum, average value （As opposed to a maximum of 800 data）
Real-time Output
Load torque value is outputted every about1/ 160 second.
(A change whole 1 / 12 seconds is possible)
Data memory Measured value - 800 data
Data output ASCII format (baud rate 19200)
Automatic clear time
In 0.1 - 3.0 seconds (0.5 seconds interval) an indication is automatically given zero.
It is a manual zero clearance by 0.0 second setup.
One-touch zero By pushing a clear button, zero adjustment can be performed by one-touch.
Battery
Ni-MH battery
(650mAh)
Ni-MH battery 1.2V×4sells (800mAh) /300 times or more charge life
Auto power OFF Power-supply OFF is carried out after the neglect during 10 minutes.
Charge time / use time About 3 hours / About 12 hours use consecutive at full charge time
Accessories
DID-05 DID-4 DIW-15 DIW-20 DIW-75 DIW-120
Bit φ4
○＋ ＃1
Bit 6.35HEX
○
＋
♯1/♯2
－ One-way socket
An exclusive case
-
An AC/DC adaptor
Result of calibration , Certification on calibration , Traceability system figure
