16. Connect after turning off power supply of all apparatus, when connecting with external apparatus.
There is fear of an electric shock or apparatus damage.
17. When situations other than contents of the operation manual occur, stop use immediately, and it is inquiry.
18. When not using a main part six months or more for quality maintenance of a battery, you have to charge once in half a
year. (There is a case where it becomes impossible to use a battery)
Cautions
1.When not using the product, keep it exactly.
(In the dry place, the high place which a child's hand does not reach or the place which a key requires)
When you convey, use the packing box containing the product.
2. Orderly dress performs. (Since there is a possibility that it may be involved in a rotation part,
neither loose clothes nor accessories, such as a necklace, are worn.)
3. It does not work with an impossible posture. (Always brace a step and maintain balance.)
4. Work, being careful enough without being inattentive.
*When using the product, it carries out by being careful enough of the method of dealing with it,
the method of work, a surrounding situation, etc.
*It is not used when it is tired.
*within the limits of common sense
(Since it has written that it is common in all of products of our company,
there is a portion which does not suit with some product.)
2 Specification
The main functions and uses of this circuit tester are explained.
2.1 The name of each part, and the main uses
①Data output terminal
⑭Pilot Lamp During Charge
⑬AC/DC
Adaptor Terminal
③ON/OFF
(Power) Key
⑧CLEAR Key
⑫System Reset
⑨Memory Display
⑩Average Display
⑦Measurement Mode Key
④DOWN・MOVE
⑥Numerical Setting Mode /
Determination Key
⑪LED Lamp
A Battery residual quantity
B Measurement mode
D The maximum, the minimum,
and an average
E 測定単位
F Torque value
C Memory data
⑤UP Key
②Display Board
Display section
E Measurement unit
