6.2 Unpack and prepare the code tape for final installation
The code tape is delivered so that it is possible to install it directly from the box. Never fully unpack the code tape initially;
otherwise the coding orientation of the code tape can be lost or the code on the code tape can be damaged. Follow
the following procedure carefully to prevent damage to the code tape and injury to the installer during installation.
Table 4: Checklist: Unpacking and preparation of the code tape
WARNING
Risk of cuts
The edges of the code tape can be sharp.
Careless handling of the code tape can
cause serious injury.
 Never grab the code tape at the edges.
 Wear appropriate protection when
handling code tape.
 Always, use/wear cut protection gloves to
protect your hands (e.g. cut level 5).
Item Section Check
1. Whenever handling the code tape, use cut protection gloves to prevent potential injury.
2. Prepare anchor point for the top tension lock.
2.1 Go with the elevator car to the top of the shaft.
2.2 Insert screw into the elevator shaft / the pit brow as anchor point for the top tension
lock. Follow the system integrator‘s instructions.
6.2.1
¨
¨
3. Prepare the code tape for installation.
3.1 Remove the top end of the code tape from the box.
3.2 Check orientation of the code tape.
3.3 Attach the top tension lock to the code tape.
3.4 Fasten the code tape with a cable tie.
3.5 Attach the code tape end cover.
6.2.2
6.2.3
6.2.3
6.2.3
6.2.3
¨
¨
¨
¨
¨
4. Unroll the code tape
4.1 Mount the top tension lock onto the anchor point.
4.2 Remove some more of the code tape from the box.
4.3 Do a “service ride” top-down to unroll the code tape.
Safety advice:
Unroll a specific length of the code tape; then travel that specific distance.
Never unroll and travel at the same time.
4.4 Let the code tape hang freely.
6.2.4
6.2.2
¨
¨
¨
¨
5. Prepare the end of the code tape at the bottom of the elevator shaft
5.1 Cut the code tape to the final operational length as detailed in the system integrator‘s
instructions. Remember to leave an additional length for the code tape end loop.
Apply a code tape end cover to the end of the remaining code tape in the box.
5.2 Attach the bottom tension lock to the code tape.
5.3 Fasten the code tape with a cable tie.
5.4 Mount the tension weight.
5.5 Apply code tape end cover.
5.6 Let the code tape hang freely.
5.7 For safety and adjustment reasons, protect the code tape against swing and vibrations
e.g. use a bucket filled with water as a vibration damper.
6.2.5
6.2.5
6.2.5
6.2.6
6.2.5
6.2.6
6.2.6
¨
¨
¨
¨
¨
¨
¨
6. The code tape is ready for final installation (clips, tension weight holder, ...) and adjustment. 6.4
