Cedes APS - 15 Dimensions (All Dimensions in MM)

APS English
26 © CEDES | V 2.2
15. Dimensions (all dimensions in mm)
APS Sensor
42.8
44
103.6
45.6
12
56.6
69
18.8
Mounting
M5x10
Mounting
M5x10
(UNC 10-24)
(UNC 10-24)
Code tape Position indicator clip Guide clip
Top and bottom tension lock Tension weight (optional)
35
312020
104
120
6
25
Ø 10.5
t=2
Ø 6 (2x)
37.2
56.2
44
10.1
5.2
10.7
Ø 6 (2x)
37.2
56.2
44
10.15.2
8.7
xx
xx
900
0.6
up to 1500 m
10
19
