14. Technical Data
Optical
Position resolution 0.5 mm
Velocity resolution 1 mm/s
Range of velocity ±0 ... 20 m/s
measurement
Distance between APS sensor 105 mm
and code tape
Readout tolerance:
- Distance ±15 mm
- Left-right ±15 mm
Mechanical
Dimensions (w × h × d) 103.6 × 56.6 × 45.6 mm
Enclosure rating IP65
Temperaturerange  −20°C...+65°C
Electrical
Supply voltage U
SP 24 VDC ±20 %
Max. current consumption 100 mA
Max. power-up inrush 200 mA
current
Termination
-CAN  100Ω(internally)
-RS485  120Ω(internally)
Scanning rate 200 Hz
Code tape
Max. length 1,500 m
Material Stainless steel body (1.4310)
Width 19 mm
Thickness 0.6 mm (steel body 0.2 mm)
Connection cable and electrical connection
Length 0.5 ... 5 m (customer specific
lengths on request)
Connector RJ45
CAN
• 1 – blue CAN Channel 1 LOW
• 2 – grey CAN Channel 1 HIGH
• 3 – green GND
• 4 – white USP
•
5 – black No function
• 6 – pink No function
• 7 – brown CAN Channel 2 LOW
• 8 – yellow CAN Channel 2 HIGH
RS485
• 1 – blue RS485 Channel 1 A
• 2 – grey RS485 Channel 1 B
• 3 – green GND
• 4 – white USP
•
5 – black No function
• 6 – pink No function
• 7 – brown No function
• 8 – yellow GND_SEC
General
EMC emission EN 12015:2014
EMC immunity EN 12016:2013
Vibration IEC 60068-2-6:2007
Shock IEC 60068-2-27:2008
RoHS 2011/65/EU
Certificates CE, TÜV, CSA
Safety category EN 61508:2010, SIL 3
EN 81–1/2 +A3:2009
EN 81-20/50:2014
CSA B44.1-14/ASME A17.5-2014
ASME A17.1-2013/CSA B44-13
