Do not start the joint cutter!
3. Apply the lever (g. 4.1) for lifting/lowering the cutting
shaft.
4. Loosen the retaining nut and adjust the required low-
ering speed with the buttery valve (g. 4.16).
5. Re-tighten the retaining nut (g. 4.16) and raise the
probably mounted saw blade from the ground.
6. Start the joint cutter and execute the cut (section
4.4.1 and chapter 5) or turn the key switch left back
to position 0 (section 4.3.2) to shut down the joint cut-
ter.
4.4 Starting and stopping
the CF-2116 D motor
DANGER!
Read and observe the motor operating
manual! The joint cutter must always be
brought to the operation site (working area) with its
motor stopped!
It is forbidden to transport the machine beyond the
operating site while the saw blade is freely rotating.
4.4.1 Starting the CF-2116 D motor
DANGER!
After having started the motor the cutting
shaft / diamond saw blade immediately
starts to rotate. Observe sections 4.5 and 4.6!
Make sure that nobody is in the danger area, especially
in front and behind the cutting direction/saw blade while
the motor is started.
DANGER!
Danger of poisoning! Never operate the
joint cutter in closed or poorly ventilated
rooms!
ATTENTION!
In order to start the motor without danger
raise the mounted diamond saw blade
from the ground / out of the cut.
As per accident prevention rules it is
absolutely necessary to wear suitable ear
protection!
Start the CF-2116 D motor as follows:
1. Disengage the feed drive (refer to section 4.4).
2. Turn the key switch right into the rst detent (1),
(section 4.3.2).
3. Raise the diamond saw blade from the ground (as
per section 4.3.1).
4. Move the motor speed lever from the stop position
until approx. 1/2 (centre position) (g. 4.8 and 4.12).
5. Turn the key switch right into the second detent (2),
(section 4.3.2).
The CF-2116 D motor starts.
The motor operating manual is decisive!
4.4.2 Stopping the CF-2116 D motor /
emergency stop
Stop the CF-2116 D motor as follows:
1. Disengage the feed drive (refer to section 4.4).
2. Raise the diamond saw blade from the ground (as
per section 4.3.1).
3. Move the motor speed lever into the stop position
(g. 4.8 and 4.12).
Emergency stop
The motor speed lever has got also the function of an
emergency stop, thus enabling to quickly shut down the
joint cutter’s motor.
The CF-2116 D motor stops!
The motor operating manual is decisive!
