Installation and control elements
• CEDIMA
®
• Technical Documentation • All rights reserved as per ISO 16016 • Subject to modications due to progressive development •
➋
➊
CF-2116 D, leading the blade guard hose ① backwards
Fig. 4.42
CF-2116 D, water tank removed, blade guard hose ① at
connection for water supplied under pressure Fig. 4.43
dirt collector ball valve with Geka-coupling
➊
ATTENTION!
Lead the external hose for water supplied
under pressure in a way that any damage
by the saw blade or tripping over is excluded.
