CEFLA MyRay Hyperion X9 - Dimensional Characteristics; Environment Characteristics

EN
OPERATOR'S MANUAL
63
10.11. DIMENSIONAL CHARACTERISTICS
Weight (basic machine)
180 Kg
Weight (cephalometric unit)
25 Kg
Maximum plan dimensions (basic machine)
1519 x 1312 mm
Maximum plan dimensions (with cephalometric unit
installed)
1519 x 1829 mm
Height
Min 1590 mm Max 2380 mm
10.12. ENVIRONMENT CHARACTERISTICS
Operating conditions
Temperature +10 - +40 °C (max. +30 °C during the
acquisition operations)
Relative humidity between 10 - 90%
Pressure 710 – 1060 hPa
Altitude < = 3000 m
Degree of pollution: 2
CTI degree: IIIb
Transport and storage conditions
Temperature -10 - +70 °C
Relative humidity between 10 - 90%
Pressure 710 – 1060 hPa
