CEFLA NewTom GO - Page 59

EN
OPERATOR'S MANUAL
59
Exposure time (PAN/CB3D)
2D mode: 1s - 15s continuous radiation (depending on
the 2D examination type selected)
3D mode: 6.4s-16.8s pulsed mode
Source distance - primary collimator
100mm
Output radiation intensity (Output dose)
0.20 mG/mAs @ 70 kV, 500 mm/
0.30 mG/mAs @ 90 kV, 500 mm/
tolerance ±30%
Source - detector distance (SID) - PAN
500 ±5 mm
Source - detector distance (SID) - CBCT
500 ±5 mm
Generator reference axis:
